ONMEAS AT6830 Insulation Resistance Tester (50kΩ~500GΩ)

Number of Channels: Single Channel

Measurement Parameters: Insulation Resistance

Output Voltage: 50V, 100V, 250V, 400V, 500V

Test Range: 50kΩ~500GΩ; 50V: 50kΩ~50GΩ; 100V: 100kΩ~100GΩ; 250V: 250kΩ~250GΩ; 400V: 400kΩ~400GΩ; 500V: 500kΩ~500GΩ

Basic Accuracy: <10G: 3%, ≥10G: 5%, ≥100G: 10%

Pre-charge Power Supply: 50V, 100V, 250V, 400V, 500V (Adjustable)

Max Charging Current: Test Voltage Source: 150mA ± 15mA, Pre-charge Voltage Source: 500mA ± 50mA

Reading: 9999

Range: Auto and Manual

Test Speed: 55 times/s, 15 times/s, 3 times/s

Correction: Full-range open circuit zeroing

Display Result: Direct reading, current, resistance, peak value, and sorting results

Charging Current: 0.5A max

Comparator: 1 set of records, HI/LO failure alarm

Instrument Size: 445mm(W) × 129mm(H) × 351mm(D)

Net Weight: 8kg

Power Requirements: Voltage: 198VAC~240VAC, Frequency: 50Hz, Power: 200VA

Interface: RS-232C Interface, Handler Interface

Communication Protocol: SCPI
