ONMEAS AT6833 Insulation Resistance Tester (25kΩ~1TΩ)

Number of Channels: Single Channel

Measurement Parameters: Insulation Resistance

Output Voltage: 100V, 250V, 500V, 750V, 1000V

Test Range: 25kΩ~1TΩ: 100V: 100kΩ~100GΩ; 250V: 250kΩ~250GΩ; 500V: 500kΩ~500GΩ; 750V: 750kΩ~750GΩ; 1000V: 1000MΩ~1000GΩ

Basic Accuracy: <10G: 3%, ≥10G: 5%, ≥100G: 10%

Pre-charge Power Supply: 100V, 250V, 500V, 750V, 1000V (Adjustable)

Max Charging Current: Test Voltage Source: 150mA ±15mA, Pre-charge Voltage Source: 500mA ±50mA

Reading: 9999

Range: Auto and Manual

Test Speed: 55/sec, 15/sec, 3/sec

Correction: Full-range Open Circuit Zeroing

Display Result: Direct Reading, Current, Resistance, Peak Value, and Sorting Result

Charging Current: 0.5A max

Comparator: 1 Set of Records, HI/LO Fail Audible Alert

Instrument Size: 445mm(W) × 129mm(H) × 351mm(D)

Weight: Net Weight: 8kg

Power Requirements: Voltage: 198VAC~240VAC, Frequency: 50Hz, Power: 200VA

Interface: RS-232C Interface, Handler Interface

Communication Protocol: SCPI Protocol
