ONMEAS AT6936 Insulation Resistance Tester (1 CH; 500W; 50V, .., 500V)

Number of Channels: 1 Channel (Test power: 500W)

Measurement Parameters: Insulation Resistance

Output Voltage: 50V, 100V, 250V, 400V, 500V

Basic Accuracy: 50V: 50kΩ~50GΩ; 100V: 100kΩ~100GΩ; 250V: 250kΩ~250GΩ; 400V: 400kΩ~400GΩ; 500V: 500kΩ~500GΩ

Test Range: Within slow range, Resistance: <1M: ±5%, ≥1M: ±1%, ≥1G: ±3%, ≥10G: ±5%

Reading: 9999

Range: Auto and Manual

Test Speed: 55 readings/s, 15 readings/s, 3 readings/s

Correction: Full range open circuit zeroing

Display Result: Direct reading, current, resistance, peak value and sorting result

Charging Current: 0.5A max

Comparator: 1 set of records, HI/LO failure alarm

Instrument Size: 445mm(W) x 129mm(H) x 351mm(D)

Net Weight: 8kg

Power Requirements: Voltage: 198VAC~240VAC, Frequency: 50Hz, Power: 200VA

Interface: RS-232C, RS-485, TYPE-C, Handler, LAN, USB
