Electronics Enclosure: IP67 polycarbonate
Accuracy: Level: ±0.25% of Range. Velocity: ±2% of Reading
Display: LCD: level, velocity, water temperature, battery, and memory capacity
Operating Temp.(Electronics): -20 °C to +60 °C (-4 °F to +140 °F)
Instrument Set Up: Via Greyline Logger software for Windows: Logging Time Interval, Site Name
Data Logger Capacity: 130,000 data points
Power Input: 4 Alkaline ‘D’ cell batteries
Output/Communications: USB
USB Cable: 914.4 mm (36 in) shielded
Software: Greyline Logger for Windows. Supports real-time monitoring, log, file, download, and export graph and data
table presentation; level / velocity to flow conversion
Approximate Shipping Weight: 4.5 kg (10 lb)
TRANSDUCER SPECIFICATIONS
Velocity Measurement Range: 0.031 m/s to 3.8 m/s (0.1 ft/s to 12.5 ft/s) in fluids containing bubbles or solids with a minimum size of 100
microns and a minimum concentration of 75 ppm to act as acoustic reflectors
Level Measurement Range: • Minimum Head: 25.4 mm (1 in)
• Maximum Head: 4.6 m (15 ft)
Operating Temperature: -15 °C to +80 °C (+5 °F to +175 °F)
Exposed Materials: 316 stainless steel, polyurethane, epoxy
Sensor Cable: 7.6 m (25 ft) submersible polyurethane jacket, shielded, 3-coaxial
Transducer Mounting: Includes MB-QZ stainless steel mounting bracket
Temperature Compensation: Automatic, continuous
POPULAR OPTIONS
Transducer Cables Extension: Shielded 15.2 m (50 ft) submersible, polyurethane jacket with watertight connectors
Sensor Mounting Bands: Stainless steel sensor mounting bands for pipes from 152.4 mm to 1.8 m (6 in to 6 ft)
Extended Temperature Sensor: QZ02L-HT, CPVC construction rated to 80 °C (175 °F)
