Voltage Range: 1000V
Voltage Accuracy: ±0.05% F.S
Voltage Resolution: 1 mV
Current Range: 300A / 400A / 600A / 1000A / 2000A…4000A
Current Accuracy: ±0.05% F.S
Current Resolution: 1 mA
Current Start Response Time: 5 ms (10%–90% F.S)
Current Switching Time: 10 ms (−90%–90% F.S)
Minimum Working Condition Simulation Interval: 20 ms
Third-party Device Integration: Supports linkage of temperature box, MTV/MTS, and I/O control box, and chiller
Cabinet Size (WDH mm): (1600–2800) * 1100 * 2000
ADVANTAGES
Support single battery voltage consistence test
Support multi-channel parallel
Power factor value up to 0.99
Anti-reverse connection and data protection
Battery discharge and energy feedback efficiency ≥96%
Three-level technology, wide voltage output, small current ripple
Support RS485/CAN battery pack communication protocol, CAN communication baud rate is changeable
Support DBC import at one-click
Support user-defined BMS values as control/protection parameters
Support slope charging and discharging
User-defined login management rights are supported
National standard plug, simulate charging pile for charging (optional)
APPLICATIONS
Applied in the testing and quality control of lithium battery modules & packs such as new energy vehicles, energy storage base stations, and can realize the integration of charging and discharging data monitoring.
