Sensata Technologies - Crydom CWA2410H インジケーター ソリッドステートリレー 90-280 VAC

Width: 44.5 mm

Height: 30.9 mm

Length: 58.8 mm

IP Rating: IP20

Output Type: SCR

Unit Weight: 86.500 g

Contact Form: SPST (1 Form A)

REACH - SVHC: Details

Input Current: 6 mA to 10 mA

Mounting Style: Panel Mount

Termination Style: Screw

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 10 A

Load Voltage Rating: 24 VAC to 280 VAC

Control Voltage Range: 90 VAC to 280 VAC

Pd - Power Dissipation: 500 mW

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 40 C
