SIGLENT SHA863A Handheld Signal Analyzer (9kHz~14 GHz)

Frequency:

Frequency range: 9 kHz ~ 14 GHz (5 kHz usable)

Frequency resolution: 1 Hz Frequency Span:

Range: 0 Hz, 100 Hz to Max Frequency

Accuracy: ± Span / (number of sweep points - 1) Internal Reference Source:

Reference frequency: 10.000000 MHz

Reference frequency accuracy / uncertainty: ± [(time since last adjustment × frequency aging rate) + temperature stability + initial calibration accuracy]

Initial calibration accuracy: < 1 ppm

Temperature stability: < 1 ppm, 0°C ~ 50°C

Frequency aging rate: < 0.5 ppm / first year, 3.0 ppm / 20 years

GPS Receiver (SHA860-GPS):

Accuracy synced to GPS: ±0.01 ppm

Accuracy un-synced to GPS: ±0.4 ppm
