SIGLENT SPS5164X プログラム可能なスイッチングDC電源 (2 channel; 160V/7.5A/720W)

Output channel: 2

Display: 2.4-inch OLED Screen

Rated output voltage: 160V

Rated output current: 7.5A

Total rated output power: 720W

Power ratio: 3.33

C.V Mode

Line regulation: 80mV (From 90~132Vac or 170~265Vac, constant load)

Load regulation: 80mV (From No load to Full load, constant input voltage)

Ripple and Noise: Noise bandwidth: 20MHz; Ripple bandwidth: 1MHz

- Ripple (pk to pk): 60mV

- RMS Ripple: 12mV

Voltage programming

- Accuracy: 0.1%±100mV

- Resolution: 1mV

Voltage readback

- Accuracy: 0.1%±100mV

- Resolution: 1mV

Temperature coefficient: 100ppm/°C from rated output voltage following 30-minute warm-up

Rise time

- Rated load: 100ms

- No load: 100ms

Fall time

- Rated load: 100ms

- No load: 1000ms

C.C Mode

Line regulation: 12mA

Load regulation: 12mA

Ripple and Noise (r.m.s): 15mA

Current setting accuracy: 0.1%±5mA

Current programming resolution: 1mA

Current readback

- Accuracy: 0.1%±5mA

- Resolution: 1mA

Temperature coefficient: 200ppm/°C from rated output current following 30-minute warm-up

Standard accessories:

USB Cable

Power cord

SPS5000X QuickStart
