Sika EME8REF-E2-0040 Digital Pressure gauge (- 1 ~ 40 bar, 0.5 %)

Pressure range: - 1 ~ 40 bar

Accuracy (± of full scale value): 0.5 %

Units: bar / mbar, kPa / MPa, PSI, kg/cm², mH₂O, inH₂O

Display: Multifunctional LCD, 4 ½ digit, with background lighting

Functions:

Bar graph

Pressure unit

Display filter

MIN/MAX value

Overpressure indication 110 % of full scale pressure value (FS)

Measuring System

Pressure measuring cell:

≤ 10 bar: bar piezo resistive

≥ 20 bar: thin film strain gauge

Temperature compensation: 0…50 °C

Temperature error: 0.005 % of full scale pressure value (FS) / K

Measuring rate actual value: 10 ms

Measuring rate bar graph: 50 ms

Process Connection

Thread ISO 1179-2: G½ with NBR gasket, AF27

Material: Stainless steel 1.4404

Medium temperature: –20…80 °C

Housing connection: 270° axially rotatable

Housing

Degree of protection (DIN EN 60529): IP67

Dimensions: Ø 90 mm, D=45 mm, H=120 mm (with protection cap)

Materials: Cast zinc with protection cap made of TPE

Ambient conditions: 0…50 °C, air humidity ≤85 % r.h.

Weight: 540 g

Vibration resistance (IEC 60068-2-6): 5g up to 500 Hz

Shock resistance (IEC 60068-2-29): 25g for 11 ms

Power Supply

Auto-off function: Selectable switch-off time 5 minutes

Battery type: 2 × 1.5 V AA

Battery operation: 1500 h

Data Logger (optional)

Max. data sets: 27,000 per recording series

Record series: 1…10

Storage rate: 0.1…6.4 s (automatically per recording duration)

Max. recording duration: 48 h

Data set information: time / actual pressure / MIN/MAX value

Digital data transmission: serial USB 2.0

Interface: Mini USB port

PC software: Detected as USB data storage device, spreadsheet program

File format: .csv
