Triplett 8066 HD CCTV Portable IP & Analog Security Camera Tester (12V/3A)

IPC Protocol: ONVIF, RTSP, RTP

Network Test: 10/100/100M detect; IP address scan, ping, packet test, DHCP server;trace route; link monitor

Rapid IP Discovery: Discover the IP address in the connected device’s network segment

WiFi: Display upload/download connection speeds: create a Wifi hotspot

IP Camera Test: Display image from the 4K H.265 camera by mainstream

Data Monitor: Capture and analyze the command data from controlling device; can also send hexadecimal

Video Test: NTSC/PAL/HD-CVI 3.0/AHD 3.0/HD-TVI 3.0

Audio Test: 1 channel audio signal input

PTZ Control Test: Support RS485; Compatible with more than 30 protocols

Lens Simulation: Simulate different lens display areas: 2.8, 3.6, 4, 6, 8, 12, 16, 25mm

POE Test Power: 48V power output; Max power 24W

12V Power Output: 12V/3A output interface

Snapshot/Video: Capture and record images and live video with playback

Memory: Internal: 3.2GB; External: optional microSD 32GB max

Display: 4” IPS touchscreen, 800 x 480

Power: Lithium-ion battery; 8 hour work time

Dimensions: 5 x 3.3 x 1.3” (126 x 83 x 33mm)
