Frequency, Min (GHz): 0
Frequency, Max (GHz): 50
VSWR, Max: 1.15:1
Durability (cycles): 500
Impedance, (Ohm): 50
Connector 1: 2.4mm
Connector 1 Gender: Male
Connector 1 Body Material: Passivated Stainless Steel
Connector 2: 2.4mm
Connector 2 Gender: Male
Connector 2 Body Material: Passivated Stainless Steel
Power Handling, CW, (W): 15
Operating Temp. Low (°C): -55
Operating Temp. High (°C): 165
Housing: Type 303 Stainless Steel-Polished&Passivated
Center Contact: Beryllium Copper Plated Gold (MIL-G-45204)
Insulators: PEI
Interfaces 1 Std: IEEE -STD-287-2007
Interfaces 2 Std: IEEE -STD-287-2007
Weight, (kg): 0.006
