Operational temperature range (°C): 300 to 1300°C (572 to 2372°F) (MB 13)
Spectral Range (µm): 1.45 to 1.8 µm
Measurement Uncertainty (°C): From 0.3% oR + 1 °C
Optics (mm): Fixed optics
FOV (minimum spot size) (mmm): Min 230:1 (1)
Alignment / Sighting: Built-in LED targeting light
Interface / Output (mA): 0/4 to 20 mA
Exposure Time t90 (ms): 2 ms
Ambient Temperature (°C): 0 to 70
Resolution (°C): 0.1
Protection Class: IP 65 (DIN 60 529)
Emissivity: 10.0 to 100.0% adjustable via interface in 0.1% steps
Weight (kg): 0.3
Housing: Stainless steel
Transmittance: 10.0 to 100.0% adjustable in 0.1% steps
Connection: 8-pin connector
Operating Position: Any
CE-label: According to EU directives about electromagnetical immunity
Parameters / Settings: Adjustable via interface: Emissivity ε, transmittance τ, exposure time t90, max/min value storage, analog output, sub temperature range, ambient temperature compensation, pyrometer address, switch contact, hysteresis, baud rate, wait time tW
Isolation: Power supply, analog output, and digital interface are galvanically isolated from each other
Wavelength Repeatability (pm): 0.2% oR + 1 °C
