Advantech 96MPI5C-3.0-9M11T 데스크탑 프로세서 CORE 3G 9M 1151P 6코어 I5-8500

Core: Intel Core i5

Family: Intel Core i5

Code Name: Coffee Lake

TDP - Max: 65 W

Memory Size: 64 GB

Memory Type: DDR4-2666

Cache Memory: 9 MB

PCIe Revision: Revision 3.0

Data Bus Width: 64 bit

Mounting Style: SMD/SMT

Number of Cores: 6 Core

System Bus Type: DMI3

Embedded Options: Embedded

Processor Series: i5-8500

System Bus Speed: 8 GT/s

Number of Threads: 6 Thread

PCIe Configurations: 1x16, 2x8, 1x8 + 2x4

ECC Memory Supported: Supported

Turbo Frequency - Max: 4.1 GHz

CPU Configuration - Max: 1 Configuration

Maximum Clock Frequency: 3 GHz

Number of Memory Channels: 2 Channel

Number of PCI Express Lanes: 16 Lane

Number of Displays Supported: 3 Display

Maximum Operating Temperature: + 100 C

Intel Hyper-Threading Technology: Without HT Technology

Lithography - Process Technology: 14 nm

Intel Virtualization Technology - VT: With VT
