Advantech 96MPI7C-2.4-12M11T 데스크탑 프로세서 CORE 2.4G 12M 1151P 6코어 I7-8700T

Core: Intel Core i7

Family: Intel Core i7

Code Name: Coffee Lake

TDP - Max: 35 W

Memory Size: 64 GB

Memory Type: DDR4-2666

Cache Memory: 12 MB

PCIe Revision: Revision 3.0

Data Bus Width: 64 bit

Mounting Style: SMD/SMT

Number of Cores: 6 Core

System Bus Type: DMI3

Embedded Options: Embedded

Processor Series: i7-8700T

System Bus Speed: 8 GT/s

Number of Threads: 12 Thread

PCIe Configurations: 1x16, 2x8, 1x8 + 2x4

ECC Memory Supported: Non-Supported

Turbo Frequency - Max: 4 GHz

CPU Configuration - Max: 1 Configuration

Maximum Clock Frequency: 2.4 GHz

Number of PCI Express Lanes: 16 Lane

Number of Displays Supported: 3 Display

Maximum Operating Temperature: + 100 C

Intel Hyper-Threading Technology: With HT Technology

Lithography - Process Technology: 14 nm

Intel Virtualization Technology - VT: With VT
