Capacity: 10N
Force Resolution: 0.0001N
Measuring range: 1% to 95% F.S.( At the time of Force measurement or take Spring rate)
Force Acuracy: ±0.2% F.S.
Unit of measurment: N (only in JAPAN) At overses it can use unit kg and lb
Test Speed: 5 to 600 mm/min
Max measurable length: 205mm
length resolution: 0.001mm
Length accuracy: ±0.05mm (with in the range 150mm)
Compression plate diameter: Upper 20mm; Lower 60mm
Hook for tensil test: 1 type
Size: W460×D350×H545 mm
Weight: Approx 45kgs
Power Supply: Selectable from AC100 to 110V, AC200 to 220V
