Alcovisor Alcotorch V9 알코올 측정기 (0 - 2.0 ‰ BAC)

Sensors:

Alcohol concentration sensor: Electrochemical sensor

Temperature sensor: MLX90614-DCC

Distance sensor: VL53L1X

Measurement modes:

Active measurement mode: Automatically checks when the preset breath volume is reached

Passive measurement mode: Starts measurement with a single button press while the user is blowing into the device

Operating temperature: -5°C to 50°C

Storage temperature: -30°C to 70°C

Dimensions: 305mm x 44mm x 44mm

Weight: 250 grams including battery

Power supply: 18.500 3.7V/1.500mAh Lithium battery

Interval between charges (lifespan): 6 hours of continuous operation and/or more than 4000 measurements

Memory: Stores the last 8000 measurements

Display: 1.3" color LCD screen

Blood alcohol concentration detection range: 0 - 2.0 ‰ BAC

Power saving: Automatically turns off after 5 minutes in alcohol concentration test mode

Body temperature measurement distance: 2 to 5 cm

Measurement time: 1 second

Accuracy:

Body temperature measurement: ± 0.2°C (in the range of 35°C to 42°C)

Blood alcohol concentration measurement at standard concentration 0.40‰ BAC:

If measured at a distance of 3 cm: ± 0.0500 ‰ BAC

If measured at a distance of 6 cm: ± 0.0600 ‰ BAC

If measured at a distance of 10 cm: ± 0.100 ‰ BAC
