Alluris FMI-S30A5 Digital Force Gauge - Solar - HR - USB (5N)

Capacity F(nom) (N) : 5

Resolution (N) : 0.001

Temperature coefficient (% / K) : 0.02

Repeatability (% F) : 0.03

Creeping (5min) (% F) : 0.15

Measuring principle:  Bidirectional force sensor with strain gauges and high-speed ?-processor

Nominal deflection ( mm) : 0.17

Measuring shaft : M6

Max. operating force  % F(nom) 120 :

Breaking force  % F(nom) : 500

Display:

Type : 5-digit | 12mm | Autoreverse

Refresh time (ms) : 10 ... 1000

Operation modes:

Regular: N | kg | lb

Peak (real-time): Display of peak value | Peak value of pull- or push force (drag indicator function)

Limits + Statistik: 2 separately adjustable limits | Single value memory and continuous measured value memory

Interface:

USB: USB 2.0 data communication

Hirose:  Limit / overload signals. digital I/O's (1 input / 3 outputs). trigger. supply (optional data cable required)

Sensor:  without

Power supply:

Type: Solar cell | USB (max. 900 mA)

Connection: USB (socket)

Temperature (operation) °C:  0 ... 40

Protection code (EN 60529) Cable not plugged:  IP40

Housing:

Material : Aluminium die cast

LxWxH (mm) : 150 x 82 x 29

Weight (kg) : 0.48

Mounting:  2xM4. 2xM5. adjusting holes D5(H7)
