Alluris FMI-S50B1 Digital Force Gauge - Solar - HR - USB-TR (10N)

Capacity F(nom) (N) : 10N

Resolution (N) : 0.002

Temperature coefficient (% / K ) : 0.02

Reproducibility (% F ) : 0.03

Repeatability( % F) : 0.03

Hysteresis (% F ) : 0.075

Creeping (5min) (% F ) : 0.15

Measuring principle : Bidirektionaler Kraftsensor mit Dehnungsmessstreifen und High-Speed ?-Prozessor

Nominal deflection( mm) : 0.34

Measuring shaft   : M6

Max. operating force (% F(nom)) : 120

Breaking force (% F(nom)) : 500

Display:

Type:  5-digit LCD | 12mm | Autoreverse

Refresh time (ms) : 10 ... 1000

Operation modes:

Regular: N | kg | lb

Peak (real-time) : Display of peak value | Peak value of pull- or push force (drag indicator function)

Limits + Statistik : 2 separately adjustable limits | Single value memory and continuous measured value memory

Interface:

USB : USB 2.0 data communication

Hirose : Limit / overload signals. digital I/O's (1 input / 3 outputs). trigger. supply (optional data cable required)

Sensor : Parallel. time-synchronous data acquisition for force and distance

Power supply:

Type S: olar cell | USB (max. 900 mA)

Connection : USB (socket)

Temperature (operation) (°C 0) :  ... 40

Protection code (EN 60529) (Cable not plugged) :  IP40

Housing:

Material : Aluminium die cast

LxWxH (mm):  150 x 82 x 29

Weight (kg): 0.48

Mounting : 2xM4. 2xM5. adjusting holes D5(H7)
