AMETEK CTS CN 200N100 Audio Transformer (10 Hz~250 kHz; 200 W)

Secondary current (saturation): 100 A rms

Secondary voltage (insulation): 1000 VDC

Ratio: 2:1 step down

Audio power: 200 W

Frequency range: 10 Hz ... 500 kHz

Primary resistance: < 5 Ω (depending on frequency)

Secondary resistance: 1/4 of primary resistance

Secondary inductance: approx. 1 mH (unloaded)

Secondary con.: 6 mm safety

Primary connectors: 6 mm safety

Dimension: 19", 3HU, 447x582x154 mm

Weight: 20 kg

Cooling: Passive Cooling

Temperature: +10 ... +40 °C

Humidity: max. 85 %, non-condensing

Athmospheric Pressure: 860 mbar ... 1060 mbar
