AMP Connectors - TE Connectivity KRP-11AG-6 표준 DPDT 10A 6VAC 6Ohm 릴레이 소켓
ModelKRP-11AG-6
문의하기
안전한 결제
품질 보장
간편 교환 및 반품
배송 가능
Width: 35.71 mm
Height: 50.8 mm
Length: 35.71 mm
Coil Type: Non-Latching
Unit Weight: 76 g
Coil Current: 335 mA
Coil Voltage: 6 VAC
Contact Form: DPDT (2 Form C)
REACH - SVHC: Details
Mounting Style: Socket
Coil Resistance: 6 Ohms
Coil Termination: Plug Pin
Contact Material: Silver Cadmium Oxide (AgCdO)
Power Consumption: 2 VA
Switching Voltage: 240 VAC
Relay Contact Form: 2 Form C (DPDT-NO, NC)
Contact Termination: Plug Pin
Contact Current Rating: 10 A
