Width: 1.25 mm
Height: 0.9 mm
Length: 2 mm
Supply Type: Single Supply
Unit Weight: 20 mg
Configuration: 1 x SPST
On Time - Max: 18 ns
Mounting Style: SMD/SMT
Off Time - Max: 12 ns
Number of Channels: 1 Channel
On Resistance - Max: 3 Ohms
Supply Current - Max: 1 uA
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.8 V
Pd - Power Dissipation: 5 uW
Switch Continuous Current: 30 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
