Anton Paar Xsample 320 Sample Changer (2 ~ 5 minutes; 10 mL ~ 20 mL)

Viscosity range: up to 3,000 mPa•s at ambient and measuring temperature¹

Filling mode: with peristaltic pump:

Suction mode in one direction

Suction mode with pumping back and forth at the beginning

Typical time for filling and measuring cycle: 2 to 5 minutes

Minimum sample volume: approx. 10 mL to 20 mL

Environmental conditions (EN 61010): indoor use only

Operating temperature: +15 °C to +35 °C (+59 °F to +95 °F)

Pollution degree: 2

Over voltage category: II

Altitude: max. 3,000 m (9,840 ft)

Power supply: supplied by the master instrument

AC power supply voltage according to technical data plate at the rear of the master instrument (protective grounding required)

Dimensions excl. master instrument (L x W x H): 205 mm x 148 mm x 205 mm (8.1 in x 5.8 in x 8.1 in)

Weight excl. master instrument: approx. 3.5 kg (7.7 lbs)

¹ Recommended for samples with a viscosity up to 500 mPa•s at ambient and measuring temperature. For samples with a viscosity higher than 500 mPa•s at ambient and measuring temperature, bubbles may occur during filling.
