Astronics R8200 Communications System Analyzer (1 MHz - 6 GHz)

Frequency Range : 1 MHz - 6 GHz

Frequency Resolution : 20 Hz

Frequency Accuracy :

Aging : ±0.1 ppm / year

Temperature : ±0.01 ppm

Measurement Bandwidths : 10 Hz to 100 kHz (1-3-10 sequence)

Temperature Stability : 0.015 dB/°C

Output Power : -3 dBm (High), -30 dBm (Low)

Accuracy of Reflection Measurement :

-15 dB to 0 dB : ±0.4 dB / ±3 deg

-25 dB to -15 dB : ±1.0 dB / ±6 deg

-35 dB to -25 dB : ±3 dB / ±20 deg

Trace Noise Magnitude (IFBW 1 kHz) : 0.005 dB rms

Measurement Speed : 100 μs/data point

Measurement Points : 101 to 10001

For details, please see Datasheet.
