■ Motor Power:15 W
■ Working Distance:80 mm
■ Weights:1×100 gram, 2×200 gram, 1×500 gram, 2×1000 gram, 1×2000 gram
■ Ring-shaped Stylus:Diamter (6.5±0.1)mm,R0.8±0.02,Thickness(1.6±0.02)mm;With smooth surface and hardness is RockWell HRC56 to HRC58 and its surface shall be smooth(roughness≤0.05 μm).
■ Stylus moving speed:3 mm/s~10 mm/s(step: 0.5mm/s)
■ Angle between stylus with test panels:45°
■ Suitalbe Test panels Width:40 mm~110 mm
■ Suitalbe Test panels Thickness:0 mm~12 mm
■ Power:Input 110~240V AC 50/60Hz(Power adapter output 24V,2A)
■ Overall Size:540mm×250mm×375mm(L×W×H)
■ Weight:15kg
