Optical system:
- Collimated illumination, diffuse vision, integrating sphere receiving mode
- Sample window size: 25mm(incident window) 21mm(exit window)
- Light source: C light（6774k）
- Receiver: silicon photovoltaic cells
Electric system:
- Large LED touch screen
- Minimum reading: 0.01%(transmittance)
- 0.01%(haze)
- USB port and USB flash drive storage
Range:
- Transmittance: 0 – 100.00%
- Haze: 0 – 30.00%
- Solid standard sample size: 50mm×50mm
Sample size
- Tank dimensions: 50mm×50mm×10mm
- Film sample size: 50mm×50mm
- imensions of the instrument: 800mm×380mm×490mm
- Weight: 27kg
Others:
- Power: 220V±22V, 50Hz±1Hz; 110V±10V,60Hz±1;
- Environment temperature: 5 – 35℃
- Accuracy of transmittance:
+ ≤±1%(Standard neutral density filter)
+ ≤±2%(Standard Haze slice)
Main technical specifications:
- Accuracy of haze: ≤±0.5%
- Repeatability of transmittance: ≤0.5%
- Repeatability of haze: ≤0.2
