Width: 20.32 mm
Height: 22.86 mm
Length: 38.1 mm
Diameter: 38.1 mm
Shielding: Unshielded
Inductance: 1.2 mH
Unit Weight: 42 g
REACH - SVHC: Details
Mounting Style: Vertical Mount
Test Frequency: 12 kHz
Termination Style: Radial
Maximum DC Current: 16 A
Number of Channels: 1 Channel
Maximum DC Resistance: 6 mOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
