Bourns CM322522-680JL 파워 인덕터 칩 인덕터 SMT 68uH

Width: 2.5 mm

Height: 2.2 mm

Length: 3.2 mm

Core Type: Wirewound

Q Minimum: 30

Shielding: Shielded

Tolerance: 5 %

Inductance: 68 uH

Application: RF

Termination: Standard

Unit Weight: 50 mg

Core Material: Ferrite

Mounting Style: PCB Mount

Test Frequency: 2.52 MHz

Termination Style: SMD/SMT

Maximum DC Current: 50 mA

Moisture Sensitive: Yes

Maximum DC Resistance: 9 Ohms

Self Resonant Frequency: 12 MHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
