Bourns SRN3015C-R24M 파워 인덕터 Ind,3x3x1.3mm,0.24uH20%,5A,shd

Width: 3 mm

Height: 1.3 mm

Length: 3 mm

Shielding: Semi-Shielded

Tolerance: 20 %

Inductance: 240 nH

Termination: Standard

Mounting Style: PCB Mount

Termination Style: SMD/SMT

Maximum DC Current: 5 A

Saturation Current: 6 A

Maximum DC Resistance: 16 mOhms

Self Resonant Frequency: 220 MHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
