Printing Technology: Thermal transfer
Resolution: 300 dpi
Print Width: up to 56.9 mm
Print Speed: up to 250 mm/s
Media Types: Paper, cardboard, PET, PE, PP, PI, PVC, PU, acrylate, Tyvec
Label Width: 4 – 63 mm
Media Thickness: 0.03 – 0.6 mm
Media Weight: 300 g/m²
Roll Diameter: up to 205 mm
Core Diameter: 38.1 – 76 mm
Ribbon Orientation: Outside or inside wound
Ribbon Roll Diameter: up to 80 mm
Ribbon Core Diameter: 25.4 mm
Ribbon Length: up to 360 m
Ribbon Width: 25 – 67 mm
Dimensions (W × H × D): 200 × 288 × 460 mm
Weight: 9 kg
Gap Sensor: Labels, punched marks, finished materials, print marks on transparent media
Reflective Sensor (bottom side): Labels, finished materials, print marks on non-transparent media
Memory: 256 MB RAM, 50 MB IFFS
Battery: Real-time clock and date/time backup
Interfaces: RS232C, USB 2.0 for PC, Ethernet 10/100 Mbit/s, USB host
Control Panel: 4.3-inch color LCD touchscreen, resolution 272 × 480 px
Power Supply: 100 – 240 VAC ~ 50/60 Hz, PFC
Power Consumption: <10 W (standby) / 100 W (typical) / max. 200 W
Operating Temperature / Humidity: +5 – 40 °C / 10 – 85% RH, non-condensing
Storage Temperature / Humidity: 0 – 60 °C / 20 – 85% RH, non-condensing
