Detector
Type: CMOS Linear Sensor
Optical parameters
Spectral range: 300–1100nm
Wavelength repeatability: ± 0.1nm @ VIS，± 0.5nm @ SWIR
Wavelength accuracy: ± 0.5nm @ VIS，± 1.1nm @ SWIR
Spectral resolution: Up to 1.7nm
Input: Spatial light (1.5m optical fiber optional)
Field of view: Standard 25°, 1°/8°/15° optional
Indicated laser wavelength: 650nm
Indicated laser power: 5mW
Maximum radiation: VNIR 2 times sunlight/SWIR 10 times sunlight
Signal-to-noise ratio: 380:1
Spectral sampling interval: 0.45nm
Number of hardware spectral averages: Up to 100 times
Electrical parameters
Operating system: Windows 11
Camera: 12 megapixels
LCD screen: 5.5 inches 720×1280 (IPS)
Integration time: 1ms–1000ms (1s) automatic optimization integration time
Data output interface: TYPE-C—USB2.0, Bluetooth
Geographic location: Built-in GPS positioning system
Angle data: JY60 gyroscope optical test angle ±180°
Power supply: Built-in battery: lithium battery 4500mAh
Battery life: Estimated 4 hours
Power supply: External power adapter: 12V 5A charging
Storage temperature: -20℃~+65℃
Operating temperature: -10~45℃
Working humidity: <90% RH (no condensation)
Physical parameters
Waterproof rating: IP65
Dimensions: 272×210×106 mm
Weight: 2.3 kg
