Coilcraft 0603HL-122XJRC RF 인덕터 0603 1200nH 언쉴드 5% 180mA 3.2옴

Width: 1.19 mm

Height: 0.94 mm

Length: 1.8 mm

Q Minimum: 14

Shielding: Unshielded

Tolerance: 5 %

Inductance: 1.2 uH

Application: RF

Termination: Standard

Unit Weight: 3.200 mg

Core Material: Ceramic

Mounting Style: PCB Mount

Test Frequency: 25 MHz

Termination Style: SMD/SMT

Maximum DC Current: 180 mA

Maximum DC Resistance: 3.2 Ohms

Self Resonant Frequency: 230 MHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
