Cable Length: 10m
Gas Detected: Oxygen
Detection Principle: Galvanic cell
Sampling Method: Diffusion Type
Detection Range (Service Range): 0 to 25.0 vol% (25.1 to 40.0 vol%)
Indication Accuracy: Within ±0.5vol%
Display Resolution: 0.1vol%
Alarm Set Value: 1st stage: 19.5vol%; 2nd stage: 18.0vol%
Response Time: Within 20 seconds
Alarm Function: Buzzer sounds, Red lamp blicks, LCD display blincks (latching), Vibration (for vibration specifications
Power Source: 2 x size AA alkaline battery (LR6/ made by PANASONIC)
Continuous Use: Approx. 15,000 hours
Explosion-Proof Structure: Ex ia II CT3 X (Japan)
Protection Class: IP20 or equivalent
Operation Temperature/Humidity: -10 to +40 °C; 30 to 85 %RH (non condensing)
Dimensions (excluding protrusions): W66 x H170 x D29 mm
Weight: Approx. 340g
