Analog Part:
Input Sensitivity: Min. 0.1 V/Digit
Load Cell Excitation: DC 5V
Non-Linearity: 0.001% of Full Scale
Input Signal: Max 3.0 mV/V
A/D Method & Sampling: Max 60 times/sec, Sigma-Delta
Resolution : Internal: 1/2,000,000 (±1,000,000), Display: 1/20,000
Display Part:
Main Display: 7 Segment, 6 Digit Red / Green Dual Color FND, H: 20mm(1inch)
Status LED: STEDY, ZERO, TARE, HOLD, RUN, TxD, RXD, OUT 1-7( 16pcs Red / Green Dual Color), Spare 2 pcs
Under ZERO Value: Minus (-) Display
Unit Display : g, kg, t, pcs, oz, lb
General Part:
Power Supply: Free Voltage (AC100V 240V, 50/60 Hz, 20W)
Operating Condition: Temperature: -10°C~+40°C, Humiduty: Under 85% F
Size/Weight: 200(W) x 100(H) x 127(D) mm / 1.25 kg
Interface: RS-232C & CURRENT
External Input: 6 EA
Relay Output: 7 EA (User Selectable)
Option: Analog Output 0~10V, 4~20mV / RS232C / RS422 RS485/BCD Input / BCD Output / Ethernet /SD Memory card / Wireles Interface
