Rated current: AC/DC 500A
Bandwidth: 500kHz
Current transfer ratio: 4mV/A
Operating temperature and humidity range: -40℃~85℃, Below 80%RH (No dew)
Promised accuracy range: 0℃~40℃, Below 80%RH
Temperature drift coefficient: 40℃~0℃﹑40℃~85℃
Amplitude Sensitivity: Below±0.02% rdg./℃
Offset Voltage:≤±0.01% f.s./℃
Diameter of measurable conductor: Φ Below 20 mm
Conductor position effect: Below ±0.1% rdg.(Input 100A, DC-100Hz, outer diameter 5mm)
Power supply voltage: Need to use with CTB104/A
Power supply capacity: Below ±300mA (500A/45Hz measurement)
