Position X10
Attenuation Ratio: 10:1
Bandwidth: DC to 250MHz
Rise Time: 1.4ns
Input Resistance: 1MΩ when used with oscilloscopes which have 1MΩ input
Input Capacitance: Approx . 13pF
Compensation Range: 10 to 30pF
Max. Input Voltage: Measurement Category 1: 500 Vrms; Measurement Category II :400 Vrms
Position X1
Attenuation Ratio: 1:1
Bandwidth: DC to 6MHz
Rise Time: 58ns
Input Resistance: 1MΩ (oscilloscope input resistance)
Input Capacitance: 65pF plus oscilloscope capacitance.
Max. Input voltage: Measurement Category 1: 150 Vrms; Measurement Category II: 150 Vrms
Operating Temperature: 0℃ to 50 ℃
Humidity: 85% RH or less (at 35℃)
Safety Meets: EN61010-031 CAT II
Cable Length: 1.2 Meter
