Specifications
Input Voltage and Frequency (External Adapter): AC/DC Power Adapter
Power Input: 100-240VAC, 50/60 Hz
Power Output: 24VDC @ 150mA
Cable Length: 5 ft. (1.5 m)
Operating Temperature: 50 to 95°F (10 to 35°C)
Environmental Requirements: Indoor use only at altitudes less than 6500 ft. (2 km) Maximum relative humidity of 80% up to 85°F (30°C) decreasing linearly to 50% @ 85°F (30°C)
Dimensions (Monitor): 3.87" L x 2.09" W x .90" H (98 mm x 53 mm x 23 mm)
Dimensions (Remote Alarm): 1.78" L x 1.08" W x .79" H (45 mm x 27 mm x 20 mm)
Weight (Monitor): 0.14 lbs. (0.06 kg)
Weight (Remote Alarm): 0.02 lbs. (0.01 kg)
Operator Test Range*: 500 kilohms to 10 megohms impedance
Worksurface Test Limit**: 10 megohms (±20%)
Operator Test Voltage: 1.2V peak-to-peak @ 1.2µA, open circuit
Worksurface Test Voltage: 5 to 7.5V, open circuit
Alarm Response Time: <50 ms
Country of Origin: United States of America
