Dimension: 65mm(W) × 55.4mm(H) × 24.3mm(D)
Input Voltage: 12 ~ 24V
Sensor: Oscillating chopper type (DIT)
Sensing Range:
- LED 1: ±100V upper ±50V under
- LED 1,2: ±50V upper ±100V under
- LED 1,2,3: ±100V upper
Response Time: 1 sec
Function: Ion balance check
Display: Color LED
Material: ABS (Conductive)
Communication: Analog output (1–5V)
Ambient Temperature: 10°C ~ 40°C (50°F ~ 104°F)
Ambient Humidity: 0 ~ 60% RH (No condensation)
