Eaton STN204033BL60 ESD 서프레서 ESD 3.3V BI

Polarity: Bidirectional

Unit Weight: 3.100 mg

Working Voltage: 3.3 V

Clamping Voltage: 18 V

Breakdown Voltage: 4.2 V

Termination Style: SMD/SMT

Moisture Sensitive: Yes

Number of Channels: 1 Channel

Cd - Diode Capacitance: 0.6 pF

Ipp - Peak Pulse Current: 20 A

Vesd - Voltage ESD Air Gap: 30 kV

Vesd - Voltage ESD Contact: 30 kV

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C

Pppm - Peak Pulse Power Dissipation: 350 W
