Working disc: Standard φ254mm with magnetic disc
Speed of working disc: 100-1000 r/min, Support clockwise / anticlockwise direction rotating
Four level constant speeds (stepless speed): V1=300r/min, V2=500r/min, V3=800r/min, V4=1000r/min (each speed can be set between 100-1000r/min)
Grinding head speed: 0-120r/min
Sample holder: Standard φ30mm 4 pieces of samples
Automatic mode: Can be programmed speed, running time and grinding wheel steering switch, with timing function
Samples pressure range: 0-0.5MPa (Commonly used 0.1-0.2Mpa)
Pressure Loading type: Single point pneumatic pressurization
Pressure adjustment: By manual (Mechanical pressure regulation)
Timing function: 0-99 minutes
Grinding head lock mode: By manual (Automatic electronic mode for optional)
Power supply: AC220V, 50/60Hz
Machine power: 1Kw
Dimension / weight: 770X730X700mm / 100kg
Packing size / G.W: 840X810X800mm / 120kg
Standard Accessory:
eGP-2A: 1
Polishing cloth with PSA (250mm): 4
Sandpaper with PSA (250mm) 400#: 4
Sandpaper with PSA (250mm) 800#: 4
Sandpaper with PSA (250mm) 1200#: 4
Waterproof ring (installed on the machine): 2
Anti-stick disc (250mm) 3 Magnetic disc (250mm): 2
Water inlet 0.75’’: 1
Power line connector(air connector): 1
Water let 32mm 1 Air pump (option): 1
Technical documents： manual, certificate, warranty card
