Voltage generators
Output range:
4-phase AC (L–N): 4 × 0–125V
2-phase AC (L–L): 2 × 0–250V
1-channel DC (L–N): 1 × 0–±125V
1-channel DC (L–L): 1 × 0–±250V
Power: 4-phase AC: 4 × 30VA; 1-channel DC: 1 × 30VA
Inaccuracy (AC): <10mV at 0–2V; ±0.2% at 2–125V
Inaccuracy (DC): <10mV at 0–5V; ±0.2% at 5–125V
Output time: Continuous
Resolution: 10mV
Current generators
Output range: 3-phase AC (L–N): 3 × 0–12.5A; 1-channel DC (L–N): 1 × 0–±6A
Power: 4-phase AC: 4 × 30VA; 1-channel DC: 1 × 30VA
Inaccuracy (AC): <2mA at 0–0.5A; ±0.2% at 0.5–12.5A
Inaccuracy (DC): <5mA at 0–1.0A; ±0.2% at 1–6.0A
Output time: 0–3A: Continuous; 3–12.5A: 60s
Resolution: 10mA
Binary inputs
Number: 2
Modes: Potential-sensing (0–250VDC) or potential-free (automatic recognition)
Max measuring time: Infinite
Binary outputs
Number: 2
Type: Quick output contacts
Update rate: 100µs
Breaking capacity: Vmax 250VDC / Imax 0.3A
Power supply
Input charge voltage: 100–240VAC
Nominal frequency: 50/60Hz
Permissible frequency: 45–65Hz
Charging voltage: 16.8V
Battery: 12.8Ah
General
Frequency range: 10–1000Hz
Frequency resolution: 0.001Hz
Angle range: –360°~360°
Phase accuracy: <0.2° (at 50/60Hz)
Phase resolution: 0.1°
Time measurement range: 0.1ms–3600s
Time measurement resolution: 0.1ms
Others
Environmental conditions: Operating temperature –10°C~50°C; Humidity ≤90%
PC connection: Ethernet, 10M/100M
Ground socket (earth): 4mm banana socket
Net size: 270×190×60mm
Net weight: 3.2kg
