Ammeter
Measurement method: AC true RMS / DC mean value
Range (Internal): 0.000–150.0A
Range (External): 0.000–6.000A (AC or DC)
Accuracy: 0.5%
Voltmeter
Measurement method: AC true RMS / DC mean value
Range: 0.0–600.0V (AC or DC)
Accuracy: 0.5%
Timer
Measurement method: 0–999.999s, automatically reset after full scale
Range: 1mS
Accuracy: ±1mS
Current outputs – AC
Range No-load voltage (min) Full-load voltage (min) Full-load current (max)
0–10A 90V 10V 10A
0–40A 25V 22V 40A
0–100A 10V 8V 100A
Voltage outputs – AC / DC
Range No-load voltage (min) Full-load voltage (min) Full-load current (max)
0–250V (AC) 250V 240V 3A
0–300V (DC) 320V 250V 4A
Auxiliary DC output
Range Voltage Max current
0–110V DC 120V DC 0.5A
110–220V DC 220V DC 0.5A
Auxiliary AC output
Range Voltage Max current
0–250V (AC) 120V AC 0.5A
0–300V (DC) 5V AC 8A
General
Operating temperature: -10°C~50°C
Humidity: ≤90%
Power supply: 200~250VAC, 50/60Hz
Power consumption: 1000W
Net size: 420×350×200 mm
Net weight: 18 kg (without measuring cables)
