Electrical:
Voltage range: 0 - ±10,000VDC
Accuracy: ±1%
Resolution: 1 Volt
Input resistance: 70 Gig Ohms
Display: 2-line LCD, backlit when using AC power.
Mechanical:
Enclosure Construction: Aluminum
Dimensions: 7.5”W x 10”D x 3”H (190 x 245 x 70mm)
Weight: 2.0 lbs. (0.91kg)
Probe:
Cable length: 36” (92cm)
Connector: High Voltage silicone rubber cable attached to unit
Body: Red plastic, 6” (15cm) long
Ground: 36” (92cm) Banana plug to banana plug w/ alligator clip
Environmental:
Operating Temp: 32 -122°F (0-50°C)
Temp coefficient: ±200ppm/°C (max)
Humidity: 0-70% RH, non-condensing
Power:
Battery: 2 x 9V Alkaline. Display indicates low battery.
AC Adapter: 90-250VAC, 50/60Hz, output 18 VDC.
