SPECIFICATIONS
Fiber type (μm): 9/125
Calibration wavelengths (nm): 1310/1550
Wavelength range (nm): 1250 to 1625
Wavelength increment (nm): 1
Maximum attenuation (dB): 65
IL (dB): ≤1.5
Resolution (dB): 0.01
Linearity (dB): ±0.1
Repeatability 2σ (dB): ±0.1
Optical return loss (dB) : >50
Max. input power (dBm): 24
Battery life (hours): >300
GENERAL SPECIFICATIONS
Size (H x W x D) 190 mm x 100 mm x 62 mm (7 ½ in x 4 in x 2 ½ in)
Weight 0.6 kg (1.3 lb)
Temperature
Operating: –10 °C to 50 °C (14 °F to 122 °F)
Storage: –40 °C to 70 °C (–40 °F to 158 °F)
Relative humidity 0 % to 95 % non-condensing
Power AC adapter and rechargeable Li-ion battery
