Applicable Station: two operators one side
Airflow Direction: Vertical
Function
Cleanliness: Class 100
Collection Efficiency: 0.3um particle ≥99.995%
Colony Count: ≤0.5/vessel (petri dish is φ 90mm )
Wind Speed: initial: 0.6（m/s）,final：0.2 （m/s）
Wind Speed Range: 0.2-0.6 （m/s）
Noise Level: ≤62db
Vibration Semi-Peak Value: ≤3um
Illumination Intensity （Lx）: ≥800LX（Activity Center）
Work Surface Bearing: 50kg
Composition
Inner Chamber: SUS304 Stainless steel plate
Outer Shell: Stainless steel electrostatic spraying exterior
Operation door: Tempered Glass
HEPA Filter （mm）: 1300*640*50 one piece
Pre-Filter （mm）: 712*360*5 one piece
Fluorescent Lamp: 24W*2
UV Lamp: 30W*1
Top Fan: 180W two pieces
Rated power: 440W
Controller
Display: LCD color screen
Wind Speed Control: Intelligent multi-level adjustable
Additional Function: Built in 2 multi-purpose sockets, high- efficiency filter, sterilization lamp replacement prompt, foot level adjustment, lighting sterilization one key on/ off
Specification
Inner Size (W*L*H)(mm): 1320*690*650
Exterior Size (W*L*H)(mm): 1460*763*1834
Max Power of universal socket: Single socket: 800W
Current Rating （50/60Hz）: AC220V/3.6A
