• Surface profile measurement according to ASTM 4417-B, SSPC-PA17, SANS 5772, US Navy NSI 009-32, US Navy PPI 63101-000
• Measuring range: 0–500μm
• Trueness: 0–100µm: ≤3µm, 100–500µm: ≤3% of nominal value
• Available with large memory space for 250,000 readings in 2500 batches
• Battery life with more than 8 hours of use
• Dimensions: 151×73×45mm (H×W×D)
• Weight (incl. batteries): 392g
• USB interface for fast and safe data transfer
With the MMS® Inspection SPG, once-tedious surface inspections can be carried out in no time at all. This handheld gauge determines the profile of the surface precisely and quickly. And you can tell right away whether the reading is within the specification or not by means of an LED light, a sound and vibrations. The profile measurements comply with ASTM 4417-B and SSPC-PA 17, among others.
Keep full control over your surface profile gauge even under the most adverse conditions: Its ergonomic design and four function keys make it easy to operate with just one hand – even when wearing gloves. And a dust- and waterproof housing (IP65) protects the surface profile gauge. So you always get reliable measurement results, regardless of the conditions you’re working in
• Measurement of surface profile depth
• Perfect for use under harsh conditions thanks to its robust housing (dustproof and protected against water jets according to IP65)
• Ergonomic design and 4 large function keys for easy one-handed operation
• Extremely easy to use: Measurement and reporting are easy, even for untrained personnel
• Full oversight of the measurement via LED, sound and vibration
• High-contrast, automatically rotating display is easy to read even in poor lighting
