FUZRR FR201E Clamp Digital Multimeter (500A AC, 600V AC/DC)

AC Current (A):

2.000 A; Accuracy: ±(3.5 % + 30)

20 A / 200 A / 500 A; Accuracy: ±(2 % + 5)

DC Voltage (V): 200 mV / 2 V / 20 V / 600 V; Accuracy: ±(0.5 % + 3)

AC Voltage (V): 2 V / 20 V / 600 V; Accuracy: ±(0.8 % + 3)

AC Voltage / Bandwidth (Hz): 400 Hz; Accuracy: –

Frequency (ACV Hz): –

Resistance (Ω):

200 Ω / 2 kΩ / 20 kΩ / 200 kΩ; Accuracy: ±(1 % + 5)

2 MΩ / 20 MΩ; Accuracy: ±(2 % + 5)

Capacitance (F): –

Temperature (°C): –

Temperature (°F): –

Display Counts: 2,000

Jaw Opening: Φ30mm

Auto Range: ●

True RMS: ●

Continuity / Diode: ●

NCV (Red LED Flashing): ●

AC Live: ●

Auto power off: ●

Max / Min: ●

Zero / Rel: ●

Backlight / Torch: ●

Battery: AAA 1.5V×2

Category Ratings: CAT III 300V CAT II 600V

Feature

AC Current: 500A

Temperature measure: 1,000℃ / 1,832℉

AC / DC Voltage: 600V

20MΩ / 40MΩ Resistance Measuring Capability

Capacitance Measuring Capability: -

Frequency Measuring Capability: -

Continuity / Diode / Duty Cycle

Max / Min, Backlight & Data Hold

NCV / LIVE, Red LED Flash & Continuity Buzzer

Torch Build In Functions As Measuring Assistance

Clamp Jaw opening 30mm
