FUZRR FR203E Clamp Digital Multimeter (400 A, 600V AC/DC)

DC Current (A): 40 A / 400 A; Accuracy: ±(2 % + 5)

AC Current (A): 40 A / 400 A; Accuracy: ±(2 % + 5)

DC Voltage (V): 600 V; Accuracy: ±(0.5 % + 3)

AC Voltage (V): 600 V; Accuracy: ±(0.8 % + 3)

LowZ AC Voltage (V): -

AC Voltage / Bandwidth (Hz): 400 Hz; Accuracy: –

AC Current / Bandwidth (Hz): 60 Hz; Accuracy: –

Frequency (ACV Hz): 40 kHz; Accuracy: ±(0.5 % + 5)

Resistance (Ω): 400 Ω ~ 400 kΩ; Accuracy: ±(1 % + 5)

Resistance (Ω): 4 MΩ ~ 40 MΩ; Accuracy: ±(2 % + 5)

Capacitance (F): 40 nF / 400 μF; Accuracy: ±(4 % + 5)

Capacitance (F): 40,000 uF; Accuracy: ±(8 % + 5)

Temperature (°C): –

Temperature (°F): –

Display Counts: 4,000

ACV LowZ: -

Jaw Opening: Φ28mm

Auto Range: ●

True RMS: ●

Continuity / Diode: ●

Auto power off: ●

Backlight / Torch: ●

Battery: AAA 1.5V × 2

Category Ratings: CAT III 300V / CAT II 600V

Feature

DC / AC Current: 400A

LowZ 100V ~ 600V

AC / DC Voltage: 600V

40MΩ / 60MΩ Resistance Measuring Capability

4mF / 60mF Capacitance Measuring Capability

40kHz / 60kHz Frequency Measuring Capability

Temperature measure: 1,000°C / 1,832°F

NCV / LIVE, Red LED Flash & Continuity Buzzer

Torch Build In Functions As Measuring Assistance

Clamp Jaw opening 28mm
