Maximum Capacity: 0-2224N
Travel (mm) approx.: 750mmx O.1mm
Speed (mm/min): 0.05 to 500 mm/min
Speed Accuracy better than: + 0.2%
Return Speed (mm/min): 500mm/min
Load Measurement Accuracy: ± 0.5% of indicated value or ± 0.1% of full scale
Load auto-zeroing: Load cell discrimination
Max. Stroke Limiter: Upper/lower — 2 points
Aluminum Disk:
Weight: 3.6 +\-O.1kg,
Dia.: 344+\-5mm.
Thickness : 12+\-1mm.
Controller: Computer with English Version
Standards:
AS 2281, ASTM F1566, ASTM D3574 Test B
ISO 3386, ISO 2439, BS EN 1957:2000
GB 10807
JISK6400
