GIGAHERTZ SOLUTIONS MK30 Electrosmog Measuring Kit (5 Hz - 100 KHz; 700 MHz - 2.7 GHz)

Item weight: 2.05 kg

Frequency range:

ME3840B:

5 Hz - 100 KHz (compensated, better than -2 dB).

Internal switchable frequency filter: 16 Hz bandpass, 50 Hz highpass, 2 kHz highpass for building biology analysis to identify railroad and mains current as well as higher frequency harmonics.

HF38B: 700 MHz - 2.7 GHz (3.3 GHz with increased tolerances)

Measurement range:

ME3840B:

Magnetic flux density (one-dimensional): 1 - 1999 nT

Electric field strength: 1 - 1999 V/m

HF38B: Power flux density: 0.01 - 19,990 µW/m²

Precision:

+/- 2 %, +/- 14 digits @ 50/60 Hz

Basic accuracy (CW) including linearity error: +/- 6 dB

Zero point deviation and special digitizing error ("rollover"): +/- 9 digits

Included Components

1x ME3840B

1x HF38B

1x K2

Manual ME3840B

Manual HF38B
