Supplied as standard: Electrode holder stand, conductivity standard, USB cable, multi-socket power supply and user manual.
Standards applied:
Performance:
Accuracy (COND): ±1 % f.s.
Salinity accuracy: ±1 % f.s.
Accuracy (TDS): ±1 % f.s.
Temperature accuracy: ±0.2 °C
Temperature coefficient (max): 0.00 ... 10.00 %/°C
Temperature compensation: 0.0 ... +100.0 %/°C
TDS factor: 0.40 ... 1.00
Measuring range (COND): 0.00 μS ... 500 mS
Salinity measuring range: 0.01 ppm ... 100 ppt
TDS measuring range: 0.1 mg/l ... 200 g/l
Temperature measurement range: -20.0 ... +120.0 °C
COND resolution: 0.01 / 0.1 / 1 (automatic scale) μS/cm - mS/cm
Temperature resolution: 0.1 °C
Working temperature: 0 ... +45 °C
Reference temperature: +15 ... +30 °C
Features:
PC communication: USB type B
Printer connection: RS 232
Display (cell constants): 0.1 / 1 / 10
Display: 4.3" high-definition, backlit colour TFT
AQA: Yes
IP rating: IP54
Inputs: BNC - RCA
Memory: 1000 data
Languages: Eng - Ita - Deu - Esp - Fra - Por
Password: Yes, 8 numeric characters
Calibration points (COND): 1 ... 4 automatic values - 1 user value
Calibration report: Yes, printable
Recognised standards (COND): 84 µS - 147 µS - 1413 µS - 12.88 mS - 111.8 mS
Display: Si
Cell type: 2 rings
Feeds:
Power supply: 100 - 240 V
Dimensions and weight:
Instrument weight: 1.255 kg
